listener

# esp32 listener
# make sure listener is running before turning on the sender
# demo of autodiscovery of espnow without hardcoded macs in the source
# queue is from uasyncio
# queue class  - https://github.com/peterhinch/micropython-async/blob/master/v3/primitives/queue.py
# espnow image - https://github.com/glenn20/micropython-espnow-images

import uasyncio
from queue import Queue
import producer

async def main():
    print("starting master...")
    q = Queue(50)
    uasyncio.create_task(producer.producer(q))

    while True:
        if not q.empty():                      # check queue for contents
            packet = await q.get()             # get one packet
            mac = packet[2:8]                  # extract mac from the packet
            message = packet[8:8 + packet[1]]  # extract message from the packet
            print(message)
            if message == b'broadcast':        # check if message is broadcast
                producer.send_message(mac, b'discovered') # acknowledge broadcast
            await uasyncio.sleep_ms(0)

        else:
            print("waiting for packet...")    # queue is empty

        await uasyncio.sleep_ms(500)

uasyncio.run(main())

sender


# esp32 sender
# make sure listener is on first
#     before turning on this sender

# color meaning:
# red    - just starting, not registered from the listener
# yellow - sent broadcast to listener
# green  - registered from the listener, sending normal messages
# blue   - empty queue message

import uasyncio
from queue import Queue
import producer
import neo

registered = False
neo_pin    = 14

async def main():
    global registered
    led = neo.Neo(neo_pin)
    led.set('red')
    q = Queue(50)
    uasyncio.create_task(producer.producer(q))
    await uasyncio.sleep_ms(500)

    ######## start of discovery ###########
    led.set('yellow')
    for _ in range(3):
        producer.broadcast()              # broadcast ourself 3 times
        await uasyncio.sleep_ms(300)

    await uasyncio.sleep_ms(200)          # give listener some time

    while True:                           # check if listener found us
        packet = await q.get()            # should check for empty
        mac = packet[2:8]                 # extract mac from packet
        message = packet[8:8 + packet[1]] # extract message from packet
        if message == b'discovered':      # listener found us
            led.set('green')
            registered = True             # our mac is registered
            break                         #     on the listener peer list
    ########## end of discovery ###########

    if registered:
        led.set('green')
        while True:
            producer.send(b'normal')      # send sensor readings... etc
            await uasyncio.sleep_ms(200)
    else:
        led.set('blue')
        print("not registered")

uasyncio.run(main())




producer

# producer.py

import network
from esp import espnow
import uasyncio

bcast = b'\xff' * 6                 # broadcast mac six bytes of \xff

wifi = network.WLAN(network.STA_IF) # espnow initialization
wifi.active(True)
e = espnow.ESPNow()
e.init()
e.add_peer(bcast)
sr = uasyncio.StreamReader(e)

# try adding peer from: https://github.com/zoland/SMesh/blob/main/smesh.py
def try_adding_peer(mac):     # add peer and check if it's already added
    try:
        e.add_peer(mac)
    except OSError as err:
        if len(err.args) < 2:
            raise err
        elif err.args[1] == 'ESP_ERR_ESPNOW_EXIST':
            ...
        else:
            raise err

async def producer(q):
    while True:
        p = await sr.read(-1)        # check for packets
        mac = p[2:8]                 # extract mac from packet
        try_adding_peer(mac)         # try adding peer to espnow
        await uasyncio.sleep_ms(0)
        if not q.full():             # check if queue is full
            await q.put(p)           # add packet to queue
        await uasyncio.sleep_ms(10)

def broadcast():
    e.send(bcast, b'broadcast', False)

def send_message(mac, message):      # send packet to particular mac
    e.send(mac, message, False)

def send(message):                   # send packet to all peers registered
    e.send(message)

def peer_info():
    return e.peer_count()




neopixel

 # neo.py
from machine import Pin, bitstream

class Neo:

    def __init__(self, pin):
        self.pin = Pin(pin, Pin.OUT)
        self.timing = (400, 850, 800, 450)
        self.buf = bytearray(b'\x00\x00\x00')

    def set(self, color):
        if color == 'red'      : self.buf = (b'\x40\x00\x00')
        elif color == 'green'  : self.buf = (b'\x00\x40\x00')
        elif color == 'blue'   : self.buf = (b'\x00\x00\x40')
        elif color == 'yellow' : self.buf = (b'\x40\x40\x00')
        elif color == 'white'  : self.buf = (b'\x40\x40\x40')
        bitstream(self.pin, 0, self.timing, self.buf)
